Designboard 227 Wood

The DESIGNBOARD 227 WOOD with the real wood veneered design surface is a surface solution for areas regulated by building authorities in which the use of not-easily flammable composite materials is required. A room-healthy alternative has been created with the Designboard, which proves itself both in terms of appearance and system safety.
Furthermore, the DESIGNBOARD 227 WOOD convinces with requirements such as sustainability, robustness and, if required, sound absorption.

DESIGNBOARD 227 WOOD can be fitted using the DESIGNBOARD FIX fastening system both as a wall and ceiling lining. The system also allows the combination of boards with different reactions to fire.

Details

Characteristics

  • Not easily flammable B-s1, d0 acc. to DIN EN 13501-1
  • Universal application
  • Robust surface
  • Good coherence of structure when exposed to fire
  • Factory veneered, formatted and edges on request
  • Highly-efficient system
  • Numerous creative design possibilities
  • Numerous optional acoustical variants available
  • Easy to apply

Application areas

The processing is carried out according to relevant standards and to detailed documentation of Knauf Design.

Usability

  • Ceiling cladding and suspended ceilings
  • Wall systems
  • Acoustic systems

Implementation

DESIGNBOARD 227 WOOD can be mounted with the Knauf Design sub-constructions split battens or DESIGNBOARD FIX.

Product variants

DESIGNBOARD 227 WOOD Unit Bulk density in kg/m³ = 1100
Realization Wood Real wood veneered
Standard formats with edge processing (max.) mm 2950 x 1200
2500 x 1200
Special format without edge processing (max.) mm 3000 x 1250
2540 x 1250
Thicknesses mm 12,4 / 15,4 / 18,4
Surface Veneered / final coated
Building material classification B-s1, d0 nach DIN EN 13501-1

Downloads

Designation Version Document type
Knauf Design DESIGNBOARD 227 WOOD March 2021 Brochure
Knauf Design DESIGNBOARD 227 WOOD June 2021 Technical data sheet
